QYT KT-A17 30W Aviation Band Mobile Radio with VHF/UHF dual-band capability. Covers 118-136MHz airband plus amateur frequencies. 200 programmable channels, PC programming, dual language menus. Professional aviation communication solution.

Key features:

Aviation frequency band 118–136 MHz

Output power: 30 W

200 channels, selectable 25 kHz / 20 kHz / 12.5 kHz spacing

Frequency stability: ±2.5 ppm

Audio output ≥2 W

Supports CTCSS/DCS/2Tone/5Tone/DTMF

Dual-language menu (Chinese/English)

Wide operating temperature range: −20 °C to +60 °C

 Professional Aviation Communication Solution

The QYT KT-A17 is a powerful 30W aviation band mobile radio designed for reliable airband communication. Supporting the aviation frequency range of 118–136 MHz, it also covers multiple VHF/UHF bands for versatile use. This professional-grade mobile transceiver delivers exceptional performance for pilots, ground crews, aircraft maintenance teams, and amateur radio operators requiring dependable aviation band communication.

Advanced Technical Specifications

With up to 200 programmable channels, Chinese and English menus, and PC programming capability, the KT-AI7 offers professional-grade performance for both ground and aviation users. The robust 30W power output ensures clear, long-range communication across demanding operational environments, while the dual-band capability provides comprehensive coverage for both aviation and amateur radio applications.

Key Features & Performance

• Aviation Band Coverage: Voice channels are between 118.000 MHz and 136.975 while the navigational channels are 108.000 MHz to 117.95 MHz.
• High Power Output: 30W transmission power for extended range communication
• Multi-Band Support: VHF/UHF coverage beyond aviation frequencies for versatile use
• Professional Programming: PC programmable with dedicated software for custom configurations
• Dual Language Support: English and Chinese menu systems for international compatibility
• 200 Memory Channels: Extensive memory capacity for frequency management
• Mobile Installation: Designed for vehicle, aircraft, and base station mounting

Applications & Use Cases

Perfect for professional aviation operations, including ground crew communications, aircraft maintenance coordination, flight training operations, and emergency response teams. Handheld air band radios pay for themselves by allowing pilots to keep in touch with the tower and conduct other in-plane activity without running the engine. The KT-A17’s mobile design makes it ideal for airport ground operations, flight schools, and aviation service providers.

Build Quality & Reliability

QYT Electronics Co.,Ltd. is a professional manufacturer with 27 years experience of producing walkie talkie,mobile radio,ham radio,walkie talkie accessory. The KT-A17 incorporates decades of radio engineering expertise, ensuring dependable performance in critical communication scenarios where reliability is paramount.

Installation & Compatibility

Designed for easy mobile installation with standard mounting brackets and connections. Compatible with external antennas, speakers, and microphones for customized setups. The radio supports both 12V and 24V power systems, making it suitable for various vehicle types and aviation applications.

FAQ

Q1: What frequency ranges does the QYT KT-A17 cover?
A1: The KT-A17 supports the aviation frequency range of 118–136 MHz, and also covers multiple VHF/UHF bands for versatile use. This includes the full aviation voice communication band plus additional amateur radio frequencies for comprehensive coverage.

Q2: What is the power output of the QYT KT-A17?
A2: The QYT KT-A17 is a powerful 30W aviation band mobile radio designed for reliable airband communication. The 30-watt output provides excellent range and clarity for both ground and air-to-ground communications.

Q3: How many channels can the KT-A17 store?
A3: The radio features up to 200 programmable channels with Chinese and English menus, and PC programming capability. This extensive memory capacity allows users to store all necessary aviation and amateur radio frequencies.

Q4: Can I program the QYT KT-A17 with a computer?
A4: Yes, the KT-A17 offers PC programming capability for advanced channel management and configuration. This allows for precise frequency programming and custom settings tailored to specific operational needs.

Q5: What power supply options are available?
A5: The KT-A17 is designed for mobile installation and typically supports both 12V and 24V power systems, making it compatible with various vehicles and aircraft electrical systems.

Q6: Is this radio suitable for professional aviation use?
A6: Absolutely. The KT-A17 offers professional-grade performance for both ground and aviation users. It’s ideal for ground crews, flight training operations, aircraft maintenance teams, and other professional aviation applications.

Q7: What is the range of aviation communication with this radio?
A7: Aviation radios can experience a range of up to 50 miles line of sight on the ground and possibly several hundred miles while flying at high altitudes. The 30W power output of the KT-A17 maximizes these range capabilities.

Q8: Does the radio support emergency frequencies?
A8: Yes, the aviation band coverage includes emergency frequencies. 121.5 MHz is the emergency distress channel which is covered within the 118-136MHz range of the KT-A17.

Q9: What makes QYT radios reliable?
A9: QYT Electronics Co.,Ltd. is a professional manufacturer with 27 years experience of producing walkie talkie, mobile radio, ham radio, and accessories. This extensive experience ensures proven reliability and performance.

Q10: Can this radio be used for both aviation and amateur radio?
A10: Yes, the KT-A17 covers multiple VHF/UHF bands for versatile use beyond just aviation frequencies, making it suitable for both aviation and amateur radio applications.

Q11: What language options are available?
A11: The radio features Chinese and English menus, providing international compatibility for users worldwide.

Q12: Is professional installation required?
A12: While professional installation is recommended for aircraft applications, the mobile design allows for standard vehicle installation using appropriate mounting brackets and antenna connections.

The post QYT KT-A17 Powerful 30W Aviation Band 118-136MHz UHF Transmit Receive Ham Mobile Radio appeared first on .

The post QYT 8900 Dual Band Mobile Radio 25W VHF UHF Red Car Transceiver appeared first on .

Product Introduction

Specifications

• Frequency Range: 120 / 300 MHz
• Total Length: 4.5 cm
• Weight: 15 g
• Connector Type: SMA-P (Male)
• Impedance: 50 Ω
• Type: 1/4 λ



The post DIAMOND SRH103 Aviation Band Antenna SMA 120-300MHz Stubby 4.5cm appeared first on .

Product Overview

The new 3350mAh battery is designed for ICOM IC-F52D, IC-F62D, IC-M85, BP-290, and BP-294 compatible walkie talkies. It offers reliable power, long runtime, and stable performance for daily communication use.

Key Features

• High capacity: 3350mAh
• Compatible with ICOM IC-F52D / IC-F62D / IC-M85
• Compatible with BP-290 / BP-294
• Rechargeable walkie talkie battery
• Suitable for wholesale and retail customers
• Ideal for two-way radio users, dealers, and repair shops

Common Use Cases

• Business communication
• Marine radio operation
• Outdoor and field work
• Security and logistics
• Radio repair and replacement

FAQ

Q1: What radios is this battery compatible with?

This battery is compatible with ICOM IC-F52D, IC-F62D, IC-M85, BP-290, and BP-294 models.

Q2: Is this a new replacement battery?

Yes, this is a new replacement battery for compatible ICOM walkie talkie radios.

Q3: Is 3350mAh good for long use?

Yes, 3350mAh offers strong battery life for extended daily communication.

Q4: Do you offer wholesale and retail?

Yes, we support both wholesale and retail orders.

The post ICOM IC-M85 Marine Waterproof Walkie-Talkie Battery 3350mAh BP-290 BP-294 for IC-F52D/IC-F62D appeared first on .

MAT-TUNER mAT-125S 120W HF SSB Antenna Auto-tuner AUTO TUNER Automatic Antenna TUNER For ICOM YAESU KENWOOD Ham Radio

mAT-125S Versatile Automatic Antenna Tuner

Compact, Versatile automatic antenna tuner for HF transceivers with up to 120W power support

The mAT-125S is a compact, versatile automatic antenna tuner designed for HF transceivers. It supports a maximum RF power of up to 120 W and operates over a wide frequency range from 1.8 to 54 MHz.

The tuner is compatible with most HF transceivers on the market and is suitable for a wide variety of antennas, including long-wire, dipole, and vertical antennas. With fast tuning performance, the mAT-125S typically completes a full tuning cycle in less than 5 seconds.

Its simple front-panel controls and clear SWR indication make operation straightforward and reliable in both fixed and portable installations. Designed for amateur radio operators who require a dependable and easy-to-use tuning solution, the mAT-125S provides stable performance for everyday HF operation.

The front panel of the mAT-125S is designed for simple and intuitive operation. It features a clear SWR LED indicator that provides a quick visual reference of the antenna match status. A dedicated power indicator shows the tuner’s operating state at a glance. The TUNE/BYPASS switch allows the user to select normal operation, initiate a tuning cycle, or bypass the tuner as required. A separate ON/OFF switch provides direct power control without the need to disconnect the power supply.

The rear panel of the mAT-125S provides all necessary connections for reliable station integration. It includes a UHF antenna connector for the antenna feed line and a UHF RF input connector for connection to the transceiver. A ground terminal is provided for connection to the station ground or grounding system to help ensure stable operation. The DC power jack accepts 12–14 V DC input, allowing the tuner to be powered from a regulated power supply or battery source.

Technical Specifications

The post MAT-TUNER mAT-125S 120W HF SSB Antenna Auto-tuner AUTO TUNER Automatic Antenna TUNER For ICOM YAESU KENWOOD Ham Radio appeared first on .

Product Overview:

 PLUTO+ is a software-defined radio platform that supports 2TX and 2RX, supports Gigabit Ethernet and Micro SD card. It refers to the design for well-known ADI ADALM-PLUTO and improves its shortcomings.

Features:

– ADC/DAC: AD9363 (Can hack to AD9361 or AD9364)

– 2 Transmit, 2 Receiving channel

– RF Range: 70MHZ~6GHZ

– Ref Clock: VCTCXO 40MHZ 0.5ppm

– SOC: for Zynq7010 FPGA: 28k

– RAM: 512M

– FLASH: 32M

– USB: 2.0, support OTG

– Ethernet: 1000Mb

– Micro SD can use to boot

– DC IN: 5V±0.5V-2A microUSB

Interfaces:

Please note that all IO levels are 1.8V.

3.1 When using the official firmware for ADI-PlutoSDR, please connect to URST-MI052.

3.2 When using Pluto+ firmware and need to support Ethernet, please connect URST-MIO46

3.3 When using SD card to boot, please connect SD-H to 1V8

3.4 When using JTAG to debug, please connect JTAG# to GND

3.5 Please connect EXCLK to GND when using external reference clock input

PTT Key Port:

– PTT drives optocouplers through GPIO0 (MI00), which requires an external relay or control circuit.

DFU KEY:

– At any time, you can press the DFU button and power on PLUTO+ again to enter the DFU mode, but you need to connect the URST jumper to MI052.

Ref CLK input IPEX:

– You can connect a cable to input an external high-precision reference clock for AD9363 through the IPEX interface.

– The main level should not exceed 3.3V, and the EXCLK jumper needs to be connected to GND to turn off the built-in clock

Calibrate the Frequency of Built-in VCTCXO:

– The frequency of the 40M clock can be fine-tuned by adjusting the adjustable resistor next to the VCTCXO, provided that you have a reference signal source.

Micro-SD:

Support booting via SD card, need to connect SD-H jumper to 1V8.

PLUTO+ Standard Package Included:

– 1 x SDR Radio PLUTO+

PLUTO+ Standard with Antenna Package Included:

– 1 x SDR Radio PLUTO+

– 1 x USB cable

– 1 x 8dBi 2.4GHz/5GHz/5.8GHz antenna

– 1 x 5dBi 40MHz-860MHz antenna

– 1 x 40MHz-6GHz telescopic antenna

– 1 x 12dBi 700MHz-2700MHz antenna

Note:

– It is assembled and ready to use.

– SD card is not included in the package.

The post Original PLUTO+ ADC/DAC AD9363 SDR Radio Receiver Transmitter 70MHz-6GHz Software Defined Radio ADI ADALM-PLUTO Plus appeared first on .

The post New XIEGU WR12 Broadband Receiver 54-1000MHz X6200 Shortwave Radio Expansion Module appeared first on .

New RC-2 CNC Aluminum Alloy Antenna Bracket ICOM Aikemu IC-705 Shortwave Radio Dedicated Compatible Adapted for ARK-705 Shield

The product has 4 options to choose from. Please purchase according to your own needs when placing an order. The package list is as shown in the SKU picture. Thank you!

1.M adapter version bracket*1 (including RF adapter, thumb screws, and hexagonal wrench*1)
2.BNC adapter version bracket*1 (including RF adapter, thumb screws, and hexagonal wrench*1)
3.M adapter version bracket*1+BNC adapter (including RF adapter, thumb screws, and hexagonal wrench*1)
4.BNC adapter (the package does not include brackets and accessories)

Please note that the 705 radio and support box are not included. (Photos are for reference only.)

product description:

Precision CNC machining, professional smooth satin finish, anodized surface

Folding tripod for easy head-up operation, silicone feet, radio lying flat

This is the original design of IC-705 shortwave radio, perfect protection.

M adapter version bracket：

————————————————————————————————

BNC adapter version bracket：

————————————————————————————————

M adapter version bracket*1+BNC adapter*1：

————————————————————————————————

BNC adapter：

Please note that the 705 radio and support box are not included. (Photos are for reference only.)

20 degree adjustable angle Compatible with different body elevation angles

The post New RC-2 CNC Aluminum Alloy Antenna Bracket ICOM Aikemu IC-705 Shortwave Radio Dedicated Compatible Adapted for ARK-705 Shield appeared first on .

Description:
– The mAT-600A is a universal high-power automatic antenna tuner compatible with nearly all transceivers and linear amplifiers. It supports a maximum RF power of 600 watts (SSB) and operates across a frequency range of 1.8-54MHz. Featuring an extremely simple operation, the tuner’s front panel contains just one button and three indicator lights.
– The unit is constructed with a full aluminum enclosure and CNC-machined panel, combining an aesthetically pleasing rugged design with relatively lightweight portability.

Features:
– Universal antenna tuner, no need to connect a dedicated data cable, supports most shortwave radio stations.
– The maximum achievable RF power is 600W (SSB). The tuning power of antenna tuner is 5-15W.
– Covering the amateur frequency range of 1.8MHz to 50MHz.
– There is only one tuning key [TUNE] in front of the antenna tuner. When the radio is in the appropriate tuning state for transmission, press and hold the tuning key for 1 second to start tuning.

Specification:

-Brand: MAT-TUNER

– Model: mAT-600A
– Frequency range: 1.8 – 54MHz
– Pass power: ≤600W (SSB)
– Tuning power: 5 – 15W
– Tuning time: ≤8s (complete tuning); 0.1s (memory tuning)
– Operating temperature: -10℃~+60℃
– Storage channel: 16000
– Power supply requirement: DC12 – 14V; ≥1A
– Product size: 192 x 75 x 193mm
– Net weight: 1.9kg

Tuning Operation Steps:
1. Set the radio station to the desired frequency, transmit power to 10W, and mode to one of CW, FM, FSK, or RTTY.
2. If you are using a linear amplifier, please switch it to the pass through state and stop the amplification function.
3. Press and hold the PTT button on the radio receiver (CW mode uses electric keys to transmit), allowing the radio to send a stable carrier wave to the antenna tuner.
4. Press and hold the [TUNE] button for 1 second before releasing it to start tuning. The “TUNING” indicator light on the front panel will light up, and during the tuning process, the tuning will make a loud noise.
5. When the “TUNING” indicator light goes out and the antenna tuner no longer makes any sound, it indicates that the antenna tuner tuning is complete. If the “ONLINE” indicator light is on, it indicates that the tuning of the tuner is successful, and if it is off, it indicates that the tuning of the tuner has failed.
6. If the tuning is successful, please restore the power and mode of the radio to the settings you need. If you are using a linear amplifier, you can set it to the amplification state and you can transmit normally.
7. If you change the operating frequency of the radio, please repeat steps 1-6 before the first transmission.

Package Included:
– 1 x Antenna Tuner
– 1 x DC Power Cable

The post mAT-600A High Power Universal Automatic Antenna Tuner 1.8-54MHz 600W Shortwave Antenna Tuner appeared first on .
