General

Frequency Range

VHF:136-174MHz UHF400-520MHz

Channel Capacity

128

Channel Spacing

25KHz/12.5KHz

Antenna Impedance

50Ω

Microphone Impedance

600Ω

Operating Voltage

7.4V DC±15%

Frequency Stability

±2.5ppm

Battery

4800mAh(Polymer Li-ion)

Compatible With American Military Standard(Mil-STD-810C/D/E)

Transmitter(EIA-RS 316B STANDARD)

RF Power Output

15W

Modulation Sensitivity

<15µV

Modulation Distortion

≤3%

Max Freq Deviation

<5KHz

Occupied Bandwidth

≤16KHz

Modulation Feature

±3dB

Spurious Radiation

≤7.5μW

Adjacent Channel Power

≤-65dB

Receiver

Sensitivity(12db SINAD)

≤0.15μ(12dB S/N)

Squelch Sensitivity

≤0.1μV

Audio Power output

1W/16Ω

Audio Respond

-6

Operation Bandwidth

>5KHz

Co-channel Rejection

≥-8dB

Blocking

≥85dB

Adjacent Channel Selectivity

≥65dB

Standby Current

60mA,15mA

Spurious Rejection

≥60dB

Intermodulation Resistance

≥60dB
